Foif RTS340 series total station
Product Description

|
Telescope
|
|
Length
|
156mm
|
|
|
Erect
|
|
Objective aperature
|
Φ45mm
|
|
Magnigication
|
30x
|
|
Field of view
|
1°30'
|
|
Shortest focus distance
|
1.0m
|
|
Angle measurement
|
|
Reading system
|
Absolute encoder(Diameter detecting)
|
|
Angle unit
|
360"/400gon/6400mil.selectable
|
|
Display resolution
|
1"/5"/10"(or 0.2/1/2mgon)
|
|
Accuracy
|
2"
|
|
Distance measurement
|
Reflectorless
|
500m
|
|
Single prism
|
3000m
|
Reflective Sheet/RP60
|
800M
|
|
Accuracy
|
1.5mm+2ppm
|
|
Measurement time
|
Initial:2.5s
|
|
Prism
|
1.0-1.5s
|
|
Display resolution (m/inch selectable )
|
0.1mm/1mm
|
|
Temperature Input range
|
-40°C to +60°C
|
|
Press input range
|
500hpa to 1500hpa
|
|
Prism constant correction
|
-99.9mm to +99.9mm
|
|
Display resolution
|
1''/5''/10''(or 0.2mgon/1mgon/2mgon)
|
|
Accuracy
|
2''
|
|
Level vial sensitivity
|
|
Plate level vial
|
30''/2mm
|
|
Circular level vial
|
8'/2mm
|
|
Compensator
|
|
Axis
|
Dual
|
|
Working range
|
±3'
|
|
Setting accuracy
|
1''
|
|
Laser plummet
|
|
Accuracy
|
±1mm/1.5m
|
|
Laser Class
|
Class 2/IEC60825-1
|
|
Laser brightness
|
Adjustable
|
|
Laser wave length
|
635nm
|
|
Optical plummet
|
|
Accuracy
|
±0.8mm/1.5m
|
|
|
Erect
|
|
Magnigication
|
3x
|
|
Field of view
|
4°
|
|
Focus range
|
0.5m to ∞
|
|
Power
|
|
Battery
|
3400mAh Li-ion Rechargeable
|
|
Output voltage
|
7.4V DC
|
|
Continuous operation time
|
Approx.26 hours
|
|
Charger
|
FDJ6-Li(110V/240V)
|
|
Charging time
|
Approx. 4 hours
|
|
Application programs
|
|
Data collection/Stake out/Resection/REM/MLM
|
|
AREA/Point to line/Z coordinate/OFFset/ Road/Tranverse
|
|
Others
|
|
CPU
|
32 Bit
|
|
Memory
|
4G internal memory ,hot-plug supported
|
|
Sensors
|
Built-in temperature and pressure sensors
|
|
Keyboard
|
Alphanumerical key board on both sides,LED backlights
|
|
Weight
|
7.0 kg
|
|
Dimensions
|
175 x 178 x340mm
|
|
Operating temperature
|
-20 to +50
|
|
Storage temperature
|
-40 to +70
|
|
Interface
|
USB/RS-232C/Bluetooth(Optional)
|
|
Water & Dust proof
|
IP66(IEC605290)
|
|
Data transfer&Processing software
|
FOIF Geomatics Office
|
|
Data collector
|
F52G,PS236, fully rugged PDA(Optional)
|
|
